Trailkat TFRHD 120 & 180

Trailkat TFRHD-120 & TFRHD-180 Features

  • HD design offers center section tandem axles that provide smooth operation over rough surfaces and slopes.
  • Deck protection rings come standard and protect the underside of the cutter deck. Clockwise rotation standard.
  • Double row safety chains along the front and rear of the mower.
  • Heavy-duty slip clutch made with nitride steel surfaces to reduce sticking in damp conditions.
  • Designed for tractors with 540 PTO. (Optional 1000 PTO available).
  • Narrow transport width allows the mower to be transported easily down narrow roads.

TFRHD-120

TFRHD-180

  • Cutting width: 126"
  • Overall width: 139"
  • Overall length: 192"
  • Transport width, min: 88"
  • Transport height: 90.5"
  • Tractor HP requirement (min): 60 HP
  • Cutting height: 1.5" to 17.5"
  • Ground clearance: 17.5"
  • Cutting width: 180"
  • Overall width: 190"
  • overall length: 192"
  • Transport width, min: 88"
  • Transport height: 90.5"
  • Tractor HP requirement (min): 65 HP
  • Cutting height: 1.5” to 17.5"
  • Ground clearance: 17.5"
